15.6″ Celeron Fanless Industrial Panel PC
R20,638.75
- Intel® Celeron® Processor J6412 (Elkhart Lake)
- 2.0 GHz (up to 2.6 GHz)
- 15.6” Full HD 1920×1080, TFT-LCD
- Projected Capacitive Touch
- IP66-rated aluminum front bezel and steel chassis
- GbE Ethernet ports x 2
- COM port x 4 (RS-232 x 2, RS-232/422/485 x 2)
- USB x 5 (3.2 Gen1 x 4, 2.0 x 1)
- DC 9~36V wide range power input
- Fan-less, modular detachable design
- VESA mounting 100x100mm / Panel mounting
Please note that items that are not currently in stock have an estimated lead time of up to 15 business days from the date your order is confirmed.
Description
System:
- CPU – Intel® Celeron® J6412 2.0GHz, quad-core, 4 threads, (up to 2.6GHz)
- System Chipset: SoC
- System Memory: 2 x SO-DIMM, DDR4 3200MHz, up to 32GB
Storage
- SSD: 1 x 2280 M.2 M-Key (PCIe x2, SATA 6Gb/s)
Expansion
- Expansion Slot: 1 x Full-size mini PCIe
Display & Touch Screen
- LCD Size: 15.6″ TFT-LCD
- Luminance (cd/m²): 350 (Typ.)
- Backlight Lifetime (hrs): 50000
- Contrast: 800: 1
- Max. Colors: 16.7M
- Max. Resolution: 1920×1080
- Viewangle (H°/V°): 178 / 178
- Touch Type: Projected Capacitive Touch (Resistive Touch as optional)
- Touch Interface: USB
- Light Transmission (%): Projected Capacitive Touch: over 85%
I/O Interface
- Audio: 1 x Line Out
- HDMI 2.0: 2
- Display Port: –
- LAN (RJ45): 2 x GbE
- Power: 1 x 2 pins terminal block for external power switch, 1 x 3 pins terminal block power connector, 1 x power switch on/off
- Serial: 1 x DB9 (RS-232/422/485 & RI/5V/12V), 1 x DB9 (RS-232/422/485), 2 x DB9 (RS-232)
- USB: 4 x USB 3.2 Gen 1, 1 x USB 2.0
Power
- Power Input: DC 9~36V
- Power Consumption: 90W
Environment
- Operating Temp: 0~50° C (32~122° F)
- Operating Humidity 10 to 90% (non-condensing)
- Storage Temp: -20~60° C (-4~140° F)
- Software: iFace-Designer® Runtime, Siemens Industrial Edge Runtime, Siemens Industrial Management
- Operating System: Windows 10 IoT, Debian 11
- Certification: CE/FCC
Mechanical
- Construction: Aluminum front bezel and steel chassis
- IP Rating: Front Panel IP66
- Mounting: VESA mounting 100x100mm / Panel mounting
- Dimension(mm): 400(W) x 249.1(H) x 87(D)
- Net Weight(Kgs): 5.5
Additional information
| Weight | 5.5 kg |
|---|---|
| Dimensions | 8.7 × 40 × 24.91 cm |
